G7L-2A-P DC24 Relay, DPST-NO, 277VAC, 25A Omron

OMRONUGS :G7L-2A-P DC24 Code de commande:2068385

Prix:
Prix ​​promotionnel€29,74

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (42 unité)

Documents et téléchargements

description

OMRON - G7L-2A-P DC24 - General Purpose Relay, G7L Series, Power, Non Latching, DPST-NO, 24 VDC, 25 A

  • Contact Configuration: DPST-NO
  • Coil Voltage: 24VDC
  • Contact Current: 25A
  • Product Range: G7L Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Contact Voltage VAC: 277VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: -
  • Contact Material: Silver Alloy
  • Coil Resistance: 303ohm
  • Approvals & Standards: CSA, IEC, UL
  • Coil Current: 79mA
  • Coil Voltage VDC Nom: 24V
  • Contact Current Max: 20A
  • Contact Voltage AC Nom: 250V
  • External Depth: 52.5mm
  • External Height: 41mm
  • External Width: 35.5mm
  • Nom Operating Power: 1.9W
  • Relay Type: Power
