G6J-2FL-Y-DC5 Relay, Signal, DPDT, 30Vdc, 1A Omron

OMRONUGS :G6J-2FL-Y-DC5 Code de commande:1448180

Prix:
Prix ​​promotionnel€7,37

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
Seulement 3 produits disponibles

Documents et téléchargements

description

OMRON - G6J-2FL-Y-DC5 - Signal Relay, 5 VDC, DPDT, 1 A, G6J-Y, Surface Mount, Non Latching

  • Coil Voltage: 5VDC
  • Contact Configuration: DPDT
  • Contact Current: 1A
  • Product Range: G6J-Y Series
  • Relay Mounting: SMD
  • Coil Type: Non Latching
  • Relay Terminals: Solder
  • Contact Voltage VAC: -
  • Contact Voltage VDC: 30V
  • Contact Material: Silver Gold
  • Coil Resistance: 173.1ohm
  • Approval Bodies: CSA
  • Approval Category: UL Recognised
  • Approvals & Standards: CSA, UL
  • Coil Current: 28.9mA
  • Coil Power Continuous: 140mW
  • Coil Voltage VDC Nom: 5V
  • Contact Current AC Max: 300mA
  • Contact Current DC Max: 1A
  • Contact Current Max: 1A
  • Contact Resistance: 100mohm
  • Contact Voltage AC Max: 125V
  • Contact Voltage AC Nom: 125V
  • Contact Voltage DC Max: 30V
  • Contact Voltage DC Nom: 30V
  • DC Coil Power: 140mW
  • Dielectric Voltage Coil to Contact: 1500VAC
  • Dielectric Voltage Contact to Contact: 1000VAC
  • External Depth: 10.6mm
  • External Height: 10mm
  • External Length / Height: 10mm
  • External Width: 5.7mm
  • Insulation Resistance: 1000Mohm
  • Insulation Resistance Voltage: 500VDC
  • No. of Electrical Operations: 100000
