G4W2212PUSTV DC24 Relay, DPST-NO, 250VAC, 24Vdc, 15A Omron

OMRONUGS :G4W2212PUSTV DC24 Code de commande:2213779

Prix:
Prix ​​promotionnel€8,06

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (19 unité)

Documents et téléchargements

description

OMRON - G4W2212PUSTV DC24 - General Purpose Relay, G4W Series, Power, Non Latching, DPST-NO, 24 VDC, 15 A

  • Contact Configuration: DPST-NO
  • Coil Voltage: 24VDC
  • Contact Current: 15A
  • Product Range: G4W Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: 24VDC
  • Contact Material: Silver Alloy
  • Coil Resistance: 720ohm
  • Coil Current: 33.3mA
  • Coil Voltage VDC Nom: 24V
  • Contact Current Max: 10A
  • Contact Voltage AC Nom: 250V
  • Contact Voltage DC Nom: 24V
  • External Depth: 30.5mm
  • External Height: 30.5mm
  • External Width: 19.5mm
  • Nom Operating Power: 800mW
  • Relay Type: Power
