G2RL-1AE DC24 Relay, SPST-NO, 250VAC, 24Vdc, 16A Omron

OMRONUGS :G2RL-1AE DC24 Code de commande:1832575

Prix:
Prix ​​promotionnel€5,06

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (59 unité)

Documents et téléchargements

description

OMRON - G2RL-1AE DC24 - General Purpose Relay, G2RL Series, Power, Non Latching, SPST-NO, 24 VDC, 16 A

  • Contact Configuration: SPST-NO
  • Coil Voltage: 24VDC
  • Contact Current: 16A
  • Product Range: G2RL Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: 24VDC
  • Contact Material: Silver Tin Oxide
  • Coil Resistance: 1.44kohm
  • Approvals & Standards: CE, UL, VDE
  • Coil Current: 16.7mA
  • Coil Voltage VDC Nom: 24V
  • Contact Current Max: 16A
  • Contact Voltage AC Nom: 250V
  • Contact Voltage DC Nom: 30V
  • External Depth: 12.7mm
  • External Height: 15.7mm
  • External Length / Height: 15.7mm
  • External Width: 29mm
  • Nom Operating Power: 400mW
  • Relay Type: Power
