G2RL-1-H DC5 RELAY, SPDT, 240VAC, 24VDC, 3A OMRON

OMRONUGS :G2RL-1-H DC5 Code de commande:2065809

Prix:
Prix ​​promotionnel€6,67

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
Seulement 2 produits disponibles

Documents et téléchargements

description

OMRON - G2RL-1-H DC5 - General Purpose Relay, G2RL Series, Power, Non Latching, SPDT, 5 VDC, 12 A

  • Contact Configuration: SPDT
  • Coil Voltage: 5VDC
  • Contact Current: 10A
  • Product Range: G2RL Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: 24VDC
  • Contact Material: Silver Tin Oxide
  • Coil Resistance: 100ohm
  • Approvals & Standards: CE, UL, VDE
  • Coil Current: 50mA
  • Coil Voltage VDC Nom: 5V
  • Contact Current Max: 10A
  • Contact Voltage AC Nom: 440V
  • Contact Voltage DC Nom: 300V
  • External Depth: 29mm
  • External Height: 15.7mm
  • External Width: 12.7mm
  • Nom Operating Power: 250mW
  • Relay Type: Power - General Purpose
