OMRON - G2R-2-S- DC24 - Power Relay, DPDT, 24 VDC, 5 A, G2RS, Socket, Non Latching
- Contact Configuration: DPDT
- Coil Voltage: 24VDC
- Contact Current: 5A
- Product Range: G2RS Series
- Relay Mounting: Socket
- Coil Type: Non Latching
- Contact Voltage VAC: 250VAC
- Relay Terminals: Quick Connect
- Contact Voltage VDC: 30VDC
- Contact Material: Silver Alloy
- Coil Resistance: 1.1kohm
- Approval Bodies: CSA, SEMKO, SEV, TUV, VDE
- Approval Category: UL Recognised
- Approvals & Standards: CE, CSA, IEC, UL, VDE
- Coil Current: 21.8mA
- Coil Voltage VDC Nom: 24V
- Contact Current AC Max: 5A
- Contact Current DC Max: 5A
- Contact Current Max: 5A
- Contact Current Min: 100mA
- Contact Resistance: 100mohm
- Contact Voltage AC Max: 250V
- Contact Voltage AC Nom: 250V
- Contact Voltage DC Max: 30V
- Contact Voltage DC Nom: 30V
- DC Coil Power: 530mW
- Dielectric Voltage Coil to Contact: 5000VAC
- Dielectric Voltage Contact to Contact: 1000VAC
- External Depth: 13mm
- External Height: 28mm
- External Length / Height: 28mm
- External Width: 29mm
- Insulation Resistance: 1000Mohm
- Insulation Resistance Voltage: 500VDC
