FN2090-16-06 Filter, 1 PH, 16A, Chassis Mount Schaffner

SCHAFFNERUGS :FN2090-16-06 Code de commande:1304862

Prix:
Prix ​​promotionnel€66,97

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (85 unité)

Documents et téléchargements

description

SCHAFFNER - FN2090-16-06 - Power Line Filter, Chassis, General Purpose, 250 VAC, 16 A, Single Phase, 2 Stage, Chassis Mount

  • Current Rating: 16A
  • Voltage Rating: 250VAC
  • Filter Type: EMI, RFI
  • Filter Terminals: Quick Connect
  • Inductance Min: 4mH
  • Capacitance: 1µF
  • Leakage Current Max: 1.02µA
  • Product Range: FN 2090 Series
  • SVHC: No SVHC (15-Jan-2019)
  • Bleed Resistor Resistance: 220kohm
  • External Depth: 45.4mm
  • External Length / Height: 113.5mm
  • External Width: 57.5mm
  • Height: 113.5mm
  • Inductance: 4µH
  • Leakage Current: 1.02µA
  • No. of Phases: Single Phase
  • Operating Temperature Max: 100°C
  • Operating Temperature Min: -25°C
  • Voltage Rating VAC: 250V
