BLOCK - FL 14/8 - PCB Transformer, Encapsulated Safety Isolating, 2 x 115V, 2 x 8V, 14 VA, 50Hz / 60Hz
- Power Rating: 14VA
- Secondary Voltages: 2 x 8V
- Current Rating: 875mA
- Isolation Transformer Primary Voltages: 2 x 115V
- Plug Type: -
- Product Range: -
- SVHC: No SVHC (12-Jan-2017)
- AC Power: 14VA
- External Depth: 24.4mm
- External Length / Height: 68mm
- External Width: 57mm
- Hole Spacing - Length: 45mm
- Input Voltage: 115V
- Lead Spacing: 10mm
- Output 2 Voltage Max: 8V
- Output Voltage: 8V
- Pin Diameter: 0.8mm
- Pitch Spacing: 15mm
- Primary Voltages: 2 x 115V
- Secondary Power: 7VA
- Supply Frequency Max: 60Hz
- Supply Frequency Min: 50Hz
- Test Voltage: 5kV
- Transformer Type: Encapsulated
- Weight: 315g
