D Subminiature
FDA-15SOL2T2/1-LF SOCKET, D, FILTERED, PCB, 15WAY CINCH CONNECTIVITY SOLUTIONS
Survolez l'image pour zoomer Cliquez sur l'image pour zoomer
FDA-15SOL2T2/1-LF SOCKET, D, FILTERED, PCB, 15WAY CINCH CONNECTIVITY SOLUTIONS

FDA-15SOL2T2/1-LF SOCKET, D, FILTERED, PCB, 15WAY CINCH CONNECTIVITY SOLUTIONS

CINCH CONNECTIVITY SOLUTIONSUGS :FDA-15SOL2T2/1-LF Code de commande:1114123
Prix:
€43,77

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
Rupture de stock

Documents et téléchargements

description

CINCH CONNECTIVITY SOLUTIONS - FDA-15SOL2T2/1-LF - D Sub Connector, Filtered, Receptacle, Cinch - FD, 15 Contacts, DA, Solder

  • Product Range: Cinch - FD Series
  • D Sub Shell Size: DA
  • Gender: Receptacle
  • No. of Contacts: 15Contacts
  • Capacitance: 1000pF
  • Connector Body Material: Steel Body
  • Contact Termination Type: Solder
  • Contact Material: Copper Alloy
  • Contact Plating: Gold over Nickel Plated Contacts
  • SVHC: No SVHC (15-Jan-2018)
  • Body Plating: Tin
  • Capacitance Min: 1nF
  • Case Material: Steel
  • Connector Mounting: Through Hole Mount
  • Contact Resistance: 5mohm
  • Contact Termination: Solder
  • D Sub Connector Type: Filtered
  • DC Current Max: 5A
  • Flammability Rating: UL94V-0
  • Insulation Resistance: 5000Mohm
  • No. of Mating Cycles: 100
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -55°C
  • Potting Encapsulation Material: Black epoxy resin
  • Working Voltage: 200V
