PANASONIC - ERA3AEB9312V - SMD Chip Resistor, 93.1 kohm, ± 0.1%, 100 mW, 0603 [1608 Metric], Metal Film (Thin Film)
- Resistor Case Style: 0603 [1608 Metric]
- Resistance: 93.1kohm
- Product Range: ERA3A Series
- Voltage Rating: 75V
- Resistor Element Material: Thin Film
- Power Rating: 100mW
- Resistance Tolerance: ± 0.1%
- Temperature Coefficient: ± 25ppm/°C
- Automotive Qualification Standard: AEC-Q200
- SVHC: No SVHC (07-Jul-2017)
- External Depth: 0.8mm
- External Length / Height: 0.45mm
- External Width: 1.6mm
- No. of Pins: 2Pins
- Operating Temperature Max: 155°C
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +155°C
- Resistor Mounting: Surface Mount Device
