ECPU1C684MA5 Cap, 0.68µF, 16V, 20%, PPS, 1206, SMD Panasonic

PANASONICUGS :ECPU1C684MA5 Code de commande:9694307

Prix:
Prix ​​promotionnel€3,01

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
Seulement 2 produits disponibles

Documents et téléchargements

description

PANASONIC - ECPU1C684MA5 - General Purpose Film Capacitor, Metallized Acrylic Stacked, 1206 [3216 Metric], 0.68 µF, ± 20%

  • Capacitance: 0.68µF
  • Voltage Rating: 16V
  • Capacitor Dielectric Type: PPS (Polyphenylene Sulphide)
  • Capacitance Tolerance: ± 20%
  • Product Range: ECPU(A) Series
  • Capacitor Case Style: 1206 [3216 Metric]
  • Capacitor Terminals: SMD
  • Lead Spacing: -
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 85°C
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2019)
  • Capacitance Tolerance ±: ± 20%
  • Capacitor Mounting: SMD
  • Dissipation Factor: 1.5%
  • External Depth: 1.4mm
  • External Length / Height: 3.2mm
  • External Width: 1.6mm
  • Height: 3.2mm
  • Insulation Resistance: 204Mohm
  • No. of Pins: 2Pins
  • Operating Temperature Range: -40°C to +85°C
  • Reel Quantity: 2000
  • Tape Width: 8mm
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Voltage Rating V DC: 16V
