XP POWER - ECM40UT33 - AC/DC Open Frame Power Supply (PSU), ITE & Medical, 3 Output, 40 W, 90V AC to 264V AC
- No. of Outputs: 3 Output
- Power Rating (Covection Cooling): 40W
- Power Rating (Forced Cooling): -
- Input Voltage VAC: 90V AC to 264V AC
- Power Supply Output Type: Adjustable, Fixed
- Output Voltage - Output 1: 5V
- Output Current - Output 1: 6A
- Output Voltage - Output 2: 15V
- Output Current - Output 2: 1.5A
- Output Voltage - Output 3: -15V
- Output Current - Output 3: 500mA
- Output Voltage - Output 4: -
- Current, Output 4: -
- Product Range: ECM Series
- SVHC: No SVHC (15-Jan-2018)
- Approval Bodies: cUL, EN, IEC, UL
- Approvals / Standards: CSA 22.2 No. 60601, EN 60601, ES 60601
- Efficiency: 85%
- Height: 30.5mm
- Input Frequency: 440Hz
- Input Voltage AC Max: 264V
- Input Voltage AC Min: 90V
- Leakage Current: 100µA
- Length: 101.6mm
- Line Regulation: 0.5%
- Load Regulation: 1%
- No. of Outputs: 3Outputs
- Output Power Max: 60W
- Output Ripple and Noise Voltage pk-pk: 1%
- Power Supply Type: Switch Mode
- Weight: 150g
- Width: 50.8mm
