ECL25US09-S PSU, Screw Terminal, 25W, 9V XP Power

XP POWERUGS :ECL25US09-S Code de commande:1738159

Prix:
Prix ​​promotionnel€85,23

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (34 unité)

Documents et téléchargements

description

XP POWER - ECL25US09-S - AC/DC Enclosed Power Supply (PSU), ITE, 1 Outputs, 25 W, 9 V, 2.8 A

  • No. of Outputs: 1Outputs
  • Output Power Max: 25W
  • Output Voltage - Output 1: 9V
  • Output Current - Output 1: 2.8A
  • Output Voltage - Output 2: -
  • Output Current - Output 2: -
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Output Voltage - Output 4: -
  • Current, Output 4: -
  • Input Voltage VAC: 85V AC to 264V AC
  • Power Supply Output Type: Fixed
  • Product Range: ECL Series
  • SVHC: No SVHC (15-Jan-2018)
  • Applications: General Purpose
  • Efficiency: 80%
  • Height: 28.5mm
  • Input Voltage AC Max: 264V
  • Input Voltage AC Min: 85V
  • Input Voltage DC Max: 370VDC
  • Input Voltage DC Min: 120VDC
  • Length: 40mm
  • No. of Outputs: 1 Output
  • Output Current Max: 2.8A
  • Peak Output Current: 3.64A
  • Power Rating: 25W
  • Supply Voltage Typ: 110V AC, 230V AC
  • Width: 96mm
