XP POWER - ECL10US24-E - AC/DC PCB Mount Power Supply (PSU), ITE, 1 Output, 10 W, 24 V, 420 mA
- No. of Outputs: 1 Output
- Output Power Max: 10W
- Output Voltage - Output 1: 24V
- Output Current - Output 1: 420mA
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Power Supply Output Type: Adjustable, Fixed
- Input Voltage VAC: 85V AC to 264V AC
- Width: 27.2mm
- Height: 23mm
- Depth: 52.4mm
- Product Range: ECL Series
- SVHC: No SVHC (15-Jan-2018)
- Approval Bodies: CSA, cUL, EN, UL
- Efficiency: 82%
- External Depth: 23mm
- External Length / Height: 52.41mm
- External Width: 27.2mm
- Frequency Max: 63Hz
- Frequency Min: 47Hz
- Input Current: 0.2A
- Input Voltage AC Max: 264V
- Input Voltage AC Min: 85V
- Input Voltage DC Max: 370VDC
- Input Voltage DC Min: 120VDC
- Inrush Current: 20A
- Length: 23mm
- Line Regulation: 0.5%
- Load Regulation: 1%
- No. of Outputs: 1Outputs
- Operating Temperature Max: 70°C
- Operating Temperature Min: -20°C
- Output Current Max: 420mA
- Output Power: 10W
- Output Ripple Voltage pk-pk: 200mV
- Peak Output Current: 0.55A
