DMS-20Pc-1-lm-C Voltmeter, AC, LED Murata Power Solutions

MURATA POWER SOLUTIONSUGS :DMS-20PC-1-LM-C Code de commande:1215406

Prix:
Prix ​​promotionnel€82,68

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (11 unité)

Documents et téléchargements

description

MURATA POWER SOLUTIONS - DMS-20PC-1-LM-C - Voltmeter, DMS-20PC Series, AC Voltage, 85V to 264V, 3 Digits, 85 V to 264 V, Red, Standoffs

  • No. of Digits / Alpha: 3
  • Meter Function: AC Voltage
  • Meter Range: 85V to 265V
  • Digit Height: 9.4mm
  • Panel Cutout Height: 21.29mm
  • Panel Cutout Width: 33.93mm
  • Supply Voltage Min: 85V
  • Supply Voltage Max: 264V
  • Operating Temperature Min: -25°C
  • Operating Temperature Max: 60°C
  • Product Range: -
  • SVHC: No SVHC (07-Jul-2017)
  • Accuracy: ± 1V
  • Backlighting Colour: Red
  • Bezel Height: 22mm
  • Bezel Width: 35mm
  • Display Area Width: 35mm
  • Display Size: 35.1mm x 22.4mm
  • Display Technology: LED
  • External Depth: 25mm
  • External Length / Height: 20mm
  • External Width: 33mm
  • LED Colour: Red
  • Leakage Current: 50mA
  • Operating Temperature Range: -25°C to +60°C
  • Resolution: 1V
  • Supply Voltage Range: 85Vrms to 264Vrms
