description
STANDEXMEDER - DIP12-2A72-21M - Reed Relay, DPST-NO, 12 VDC, DIP, Through Hole, 500 ohm, 500 mA
- Contact Configuration: DPST-NO
- Coil Voltage: 12VDC
- Product Range: DIP Series
- Relay Mounting: Through Hole
- Coil Resistance: 500ohm
- Switching Current Max: 500mA
- Switching Voltage Max: 200V
- Coil Voltage VDC Nom: 12V
- External Depth: 20.5mm
- External Height: 8.2mm
- External Width: 8mm
