DIP05-2A72-21L Relay, Reed, DPST-NO, 200V, 0.5A, THT Standexmeder

STANDEXMEDERUGS :DIP05-2A72-21L Code de commande:1079443

Prix:
Prix ​​promotionnel€11,83

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (51 unité)

Documents et téléchargements

description

STANDEXMEDER - DIP05-2A72-21L - Reed Relay, DPST-NO, 5 VDC, DIP, Through Hole, 200 ohm, 500 mA

  • Contact Configuration: DPST-NO
  • Coil Voltage: 5VDC
  • Product Range: DIP Series
  • Relay Mounting: Through Hole
  • Coil Resistance: 200ohm
  • Switching Current Max: 500mA
  • Switching Voltage Max: 200V
  • SVHC: No SVHC (15-Jan-2018)
  • Approval Bodies: UL
  • Coil Voltage Max: 7.5VDC
  • Coil Voltage VDC Nom: 5V
  • Contact Current AC Max: 1A
  • Contact Current DC Max: 1A
  • Contact Current Rating: 1.25A
  • Contact Resistance: 150mohm
  • Contact Voltage AC Max: 200V
  • Contact Voltage DC Max: 200V
  • External Depth: 19.3mm
  • External Height: 7.5mm
  • External Length / Height: 7.5mm
  • External Width: 7mm
  • No. of Pins: 8Pins
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: -20°C
  • Operating Time: 0.5ms
  • Release Time: 0.1ms
  • Switch Current Max: 1A
  • Switch Power Max: 20W
