DILM150(RAC240) Relay, 3PST-NO, 690VAC, 150A Eaton Moeller

EATON MOELLERUGS :DILM150(RAC240) Code de commande:1459198

Prix:
Prix ​​promotionnel€975,35

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
Seul 1 produit disponible

Documents et téléchargements

description

EATON MOELLER - DILM150(RAC240) - Contactor, DIN Rail, Panel, 690 VAC, 3PST-NO, 3 Pole, 75 kW

  • Load Current Inductive: -
  • Relay Mounting: DIN Rail, Panel
  • Operating Voltage: 690VAC
  • Contact Configuration: 3PST-NO
  • No. of Poles: 3 Pole
  • Switching Power AC3: 75kW
  • Switching Current AC1: 180A
  • Coil Voltage VAC Nom: 240V
  • Coil Voltage VDC Nom: -
  • Switching Power AC1: -
  • Load Current Resistive: -
  • Switching Current AC3: 150A
  • Product Range: DILM
  • SVHC: No SVHC (17-Dec-2015)
  • Approval Bodies: CSA, EN, IEC, UL, VDE
  • Coil Voltage: 240V
  • Coil Voltage Max: 240VAC
  • Contact Current: 150A
  • Contact Current AC Max: 150A
  • Contact Voltage AC Max: 400V
  • Contact Voltage VAC: 690V
  • Dielectric Voltage Coil to Contact: 440VAC
  • Dielectric Voltage Contact to Contact: 440VAC
  • External Depth: 176mm
  • External Height: 170mm
  • External Length / Height: 170mm
  • External Width: 90mm
  • Insulation Voltage: 690VAC
  • Main Contact Current AC3 Max: 150A
  • Power Rating: 75kW
  • Relay Terminals: Screw
  • Relay Type: Contactor
