VISHAY - CDHVAF25M0F2500FET - Resistor Network, 100 kohm, CDHV, 25 Mohm, 2 Elements, Voltage Divider, 2512 [6432 Metric]
- Resistance R1: 100kohm
- Product Range: CDHV Series
- Resistance R2: 25Mohm
- No. of Elements: 2Elements
- Network Circuit Type: Voltage Divider
- Resistor Case Style: 2512 [6432 Metric]
- No. of Pins: 3Pins
- Power Rating per Element: -
- Absolute Resistance Tolerance: ± 1%
- Absolute TCR: ± 100ppm/°C
- Automotive Qualification Standard: -
- Operating Temperature Max: 150°C
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +150°C
- Resistance: 25Mohm
- Resistance Tolerance: ± 1%
- Resistor Mounting: Surface Mount Device
- Temperature Coefficient: ± 100ppm/°C
- Voltage Rating: 3kV
