CA2KN40U7 Relay, 4PST-NO, 690VAC, 10A Schneider Electric

SCHNEIDER ELECTRICUGS :CA2KN40U7 Code de commande:288494

Prix:
Prix ​​promotionnel€64,71

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
Seulement 4 produits disponibles

Documents et téléchargements

description

SCHNEIDER ELECTRIC - CA2KN40U7 - General Purpose Relay, CA Series, Power, 4PST-NO, 240 VAC, 10 A

  • Contact Configuration: 4PST-NO
  • Coil Voltage: 240VAC
  • Contact Current: 10A
  • Product Range: CA Series
  • Relay Mounting: DIN Rail, Panel
  • Coil Type: AC
  • Contact Voltage VAC: 690VAC
  • Relay Terminals: Screw
  • Contact Voltage VDC: -
  • Contact Material: -
  • Coil Resistance: -
  • SVHC: No SVHC (15-Jan-2018)
  • AC Coil Power: 4.5VA
  • Approval Bodies: BIA, INRS
  • Coil Operating Lower Percent Limit: 70%
  • Coil Operating Upper Percent Limit: 130%
  • Coil Voltage VAC Nom: 240V
  • Contact Current AC Max: 10A
  • Contact Current Max: 10A
  • Contact Voltage AC Max: 690V
  • Contact Voltage AC Nom: 690V
  • DC Coil Power: 1.5W
  • External Depth: 57mm
  • External Height: 58mm
  • External Length / Height: 58mm
  • External Width: 45mm
  • Height: 58mm
  • Main Contact Current AC1 Max: 10A
  • Nom Operating Power: 30VA
  • Relay Type: Power
  • Termination Type: Screw Clamp
