C1520ATAAA Rocker Switch, SPDT, Ctr Off Arcolectric (Bulgin Limited)

ARCOLECTRIC (BULGIN LIMITED)UGS :C1520ATAAA Code de commande:150551

Prix:
Prix ​​promotionnel€4,66

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (316 unité)

Documents et téléchargements

description

ARCOLECTRIC (BULGIN LIMITED) - C1520ATAAA - Rocker Switch, On-Off-On, SPDT, Non Illuminated, Panel Mount, Black, 1500

  • Illumination: Non Illuminated
  • Contact Configuration: SPDT
  • Switch Operation: On-Off-On
  • Actuator / Cap Colour: Black
  • Switch Mounting: Panel
  • Contact Current Max: 16A
  • Contact Voltage AC Nom: 250V
  • Contact Voltage DC Nom: -
  • Product Range: 1500 Series
  • SVHC: No SVHC (27-Jun-2018)
  • Bezel Height: 14mm
  • Bezel Width: 30.2mm
  • Colour: Black
  • Contact Current AC Max: 10A
  • Contact Current DC Max: 16A
  • Contact Resistance: 10Mohm
  • Contact Voltage AC Max: 250V
  • External Depth: 16.2mm
  • Insulation Resistance: 20Mohm
  • No. of Electrical Operations: 10000
  • No. of Mechanical Operations: 50000
  • Operating Temperature Max: 125°C
  • Operating Temperature Min: 0°C
  • Panel Cutout Size: 11.5 x 28.2 mm
  • Panel Cutout Width: 11.5mm
  • Panel Cutout length: 28.2mm
  • Tab Blade Thickness: 0.8mm
  • Tab Width: 6.35mm
