EPCOS - B88069X8300B502 - Gas Discharge Tube (GDT), Low Capacitance, T83A90X, 90 V, 3 Terminal Through Hole, 10 kA, 400 V
- Product Range: T83A90X Series
- DC Breakover Voltage: 90V
- GDT Case Style: 3 Terminal Through Hole
- Impulse Discharge Current: 10kA
- Impulse Sparkover Voltage: 400V
- SVHC: No SVHC (27-Jun-2018)
- Body Diameter: 8mm
- Capacitance: 1.5pF
- Discharge Current AC Max: 10kA
- External Length / Height: 13.4mm
- Impulse Discharge Current Max: 10kA
- Insulation Resistance: 10Gohm
- Lead Diameter: 1mm
- Operating Temperature Max: 90°C
- Operating Temperature Min: -40°C
- Sparkover Voltage DC: 90V
- Suppressor Type: Gas Discharge Tube (GDT)
