EPCOS - B59300M1160A070 - PTC Thermistor, 300 ohm, Through Hole, 30 V, B59300 Series
- Zero Power Resistance at 25°C: 300ohm
- Thermistor Mounting: Through Hole
- Product Range: B59300 Series
- Operating Voltage Max: 30VDC
- Applications: Limit Temperature Monitoring & Thermal Protection
- Operating Temperature Min: 0°C
- Operating Temperature Max: 40°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (27-Jun-2018)
- Body Diameter: 3mm
- External Length / Height: 520mm
- Lead Diameter: 0.42mm
- Lead Length: 510mm
- Operating Temperature Range: 0°C to +40°C
- Operating Voltage: 30V
- Resistance: 300ohm
- Resistance @ Temperature: 300ohm
- Resistance Temperature: 25°C
- Thermistor Type: PTC
- Threshold Temperature: 160°C
- Tripping Temperature: 160°C
- Voltage Rating V DC: 30V
