ALS30A472NP400 Cap, 4700µF, 400V, Alu Elec, Screw Kemet

KEMETUGS :ALS30A472NP400 Code de commande:776890

Prix:
Prix ​​promotionnel€92,60

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (53 unité)

Documents et téléchargements

description

KEMET - ALS30A472NP400 - Electrolytic Capacitor, Long Life, 4700 µF, 400 V, ± 20%, Screw, 20000 hours @ 85°C

  • Capacitance: 4700µF
  • Voltage Rating: 400V
  • Product Range: ALS30 Series
  • Lifetime @ Temperature: 20000 hours @ 85°C
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Screw
  • Diameter: 77mm
  • Lead Spacing: 31.7mm
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 85°C
  • Height: 146mm
  • ESR: 0.033ohm
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2018)
  • AC Ripple Current @ 100Hz: 18A
  • AC Ripple Current @ 10kHz: 24.2A
  • Capacitance Tolerance ±: ± 20%
  • Climatic Category: 40/085/56
  • ESR Frequency: 100Hz
  • ESR Temperature: 20°C
  • External Length / Height: 146mm
  • Leakage Current: 10000µA
  • No. of Pins: 2Pins
  • Operating Life Temperature: 85°C
  • Operating Temperature Range: -40°C to +85°C
  • Operating life Time: 11000h
  • Ripple Current AC: 18A
  • Ripple Current Frequency: 100Hz
  • Ripple Current Temperature: 85°C
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Voltage Rating V DC: 400V
