AGN200A12 Relay, Signal, DPDT, 30Vdc, 1A Panasonic

PANASONICUGS :AGN200A12 Code de commande:3104801

Prix:
Prix ​​promotionnel€3,08

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (136 unité)

Documents et téléchargements

description

PANASONIC - AGN200A12 - Signal Relay, 12 VDC, DPDT, 1 A, AGN, Surface Mount, Non Latching

  • Coil Voltage: 12VDC
  • Contact Configuration: DPDT
  • Contact Current: 1A
  • Product Range: AGN Series
  • Relay Mounting: SMD
  • Coil Type: Non Latching
  • Relay Terminals: Solder
  • Contact Voltage VAC: -
  • Contact Voltage VDC: 30V
  • Contact Material: Silver Palladium
  • Coil Resistance: 1.028kohm
  • SVHC: No SVHC (07-Jul-2017)
  • Approvals & Standards: CSA, UL
  • Coil Current: 11.7mA
  • Coil Power Continuous: 140mW
  • Coil Voltage VDC Nom: 12V
  • Contact Current AC Max: 300mA
  • Contact Current DC Max: 1A
  • Contact Current Max: 1A
  • Contact Voltage AC Max: 125V
  • Contact Voltage AC Nom: 125V
  • Contact Voltage DC Max: 30V
  • Contact Voltage DC Nom: 30V
  • DC Coil Power: 140mW
  • External Depth: 10.6mm
  • External Height: 9mm
  • External Length / Height: 10.6mm
  • External Width: 5.7mm
  • Nom Operating Power: 140mW
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -40°C
  • Operating Time: 4ms
  • Relay Type: General Purpose
  • Release Time: 4ms
  • Switch Current Max: 1A
  • Switching Current Max: 1A
