PANASONIC - AGN20024 - Signal Relay, 24 VDC, DPDT, 1 A, AGN, Through Hole, Non Latching
- Coil Voltage: 24VDC
- Contact Configuration: DPDT
- Contact Current: 1A
- Product Range: AGN Series
- Relay Mounting: Through Hole
- Coil Type: Non Latching
- Relay Terminals: Solder
- Contact Voltage VAC: -
- Contact Voltage VDC: 30V
- Contact Material: Silver Palladium
- Coil Resistance: 2.504kohm
- SVHC: No SVHC (07-Jul-2017)
- Approvals & Standards: CSA, UL
- Coil Current: 9.6mA
- Coil Power Continuous: 230mW
- Coil Voltage VDC Nom: 24V
- Contact Current Max: 1A
- Contact Voltage AC Nom: 125V
- Contact Voltage DC Nom: 30V
- External Depth: 10.6mm
- External Height: 9mm
- External Width: 5.7mm
