86104CY Data Cable 26AWG, SCRN 4CORE, Per M Alpha Wire

ALPHA WIREUGS :86104CY Code de commande:1515265

Prix:
Prix ​​promotionnel€10,88

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (56 unité)

Documents et téléchargements

description

  • Cable Shielding: Screened
  • No. of Cores: 4Core
  • Wire Gauge: 26AWG
  • Conductor Area CSA: 0.14mm²
  • Reel Length (Imperial): -
  • Reel Length (Metric): -
  • Jacket Colour: Grey
  • No. of Max Strands x Strand Size: 7 x 0.16mm
  • Conductor Material: Copper
  • Jacket Material: PVC
  • External Diameter: 5mm
  • Voltage Rating: 300V
  • Product Range: Xtra-Guard&reg
  • SVHC: No SVHC (15-Jan-2019)
  • Bend Flexing Radius Min: 8 X Cable Diameter
  • Cable Type: Foil + Spiral Shield
  • Conductor Make-up: 7 / 0.16mm
  • External Length / Height: 1m
  • Operating Temperature Max: 105°C
  • Operating Temperature Min: 5°C
  • Outer Diameter: 5mm
  • Primary Insulation Thickness: 0.25mm
  • Secondary Insulation Colour: Grey
  • Secondary Insulation Material: PVC
  • Secondary Insulation Thickness: 1mm
  • Voltage Rating VAC: 300V
  • Wire Size: 26AWG
