8-188275-0 Connector, Rcpt, 10Pos, 2Row, 1.27mm Amp - Te Connectivity

AMP - TE CONNECTIVITYUGS :8-188275-0 Code de commande:2399718

Prix:
Prix ​​promotionnel€2,16

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (1800 unité)

Documents et téléchargements

description

AMP - TE CONNECTIVITY - 8-188275-0 - PCB Receptacle, Board-to-Board, 1.27 mm, 1 Rows, 10 Contacts, Surface Mount Straight, Micro-MaTch

  • Pitch Spacing: 1.27mm
  • No. of Contacts: 10Contacts
  • Gender: Receptacle
  • Product Range: Micro-MaTch Series
  • Contact Termination Type: Surface Mount
  • No. of Rows: 2Rows
  • Contact Plating: Tin Plated Contacts
  • Contact Material: Phosphor Bronze
  • SVHC: No SVHC (27-Jun-2018)
  • Contact Resistance: 50mohm
  • Contact Termination: Surface Mount Vertical
  • Insulator Material: PBT (Polybutylene Terephthalate), Glass Filled
  • Lead Spacing: 1.27mm
  • Operating Temperature Max: 105°C
  • Operating Temperature Min: -40°C
  • Termination Method: Solder
  • Voltage Rating VAC: 230V
  • Wire Size AWG Max: 28AWG
