78615/1C Transformer, Pulse, 1CT:1CT, 2000UH Murata Power Solutions

MURATA POWER SOLUTIONSUGS :78615/1C Code de commande:1454887

Prix:
Prix ​​promotionnel€2,72

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (40 unité)

Documents et téléchargements

description

MURATA POWER SOLUTIONS - 78615/1C - Pulse Transformer, PCB, 1CT:1CT, 2 mH, 0.6 ohm, 20 Vµs, 1 kV, 78615/1C Series

  • TRANSFORMER, PULSE, 1CT: 1CT, 2000UH
  • Turns Ratio: 1CT
  • Isolation Voltage: 1kV
  • Product Range: 786 Series
  • Inductance: 2mH
  • DC Resistance: 0.6ohm
  • ET Constant: 20Vµs
  • SVHC: No SVHC (07-Jul-2017)
  • Capacitance: 16µF
  • External Depth: 6.35mm
  • External Length / Height: 9.52mm
  • External Width: 8.89mm
  • Flammability Rating: UL94V-0
  • Leakage Inductance: 16µH
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: 0°C
  • Primary Inductance: 2000µH
  • Secondary Resistance: 0.6ohm
  • Transformer Type: Pulse
  • Winding Configuration: 1CT
  • Winding Resistance Max: 0.6ohm
