MURATA POWER SOLUTIONS - 77208C - Pulse Transformer, PCB, 1:1:1, 16.3 mH, 3.6 ohm, 482 Vµs, 2.5 kV, 77208C Series
- TRANSFORMER, PULSE, 1: 1
- Turns Ratio: 1
- Isolation Voltage: 2.5kV
- Product Range: 772 Series
- Inductance: 16.3mH
- DC Resistance: 3.6ohm
- ET Constant: 482Vµs
- SVHC: No SVHC (07-Jul-2017)
- Capacitance: 40pF
- External Length / Height: 13mm
- Flammability Rating: UL94V-0
- Leakage Inductance: 40µH
- Primary Inductance: 16.3mH
- Primary Resistance: 3.6ohm
- Proof Voltage PK: 3.5kV
- Secondary Resistance: 3.1ohm
- Transformer Type: Pulse
- Winding Configuration: 1
- Winding Resistance Max: 4.2ohm
- Working Voltage: 600V
