55.14.8.230.0000 Relay, 4PDT, 250VAC, 7A Finder

FINDERUGS :55.14.8.230.0000 Code de commande:1169255

Prix:
Prix ​​promotionnel€19,53

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
Seulement 3 produits disponibles

Documents et téléchargements

description

FINDER - 55.14.8.230.0000 - General Purpose Relay, 55 Series, Power, 4PDT, 230 VAC, 7 A

  • Contact Configuration: 4PDT
  • Coil Voltage: 230VAC
  • Contact Current: 7A
  • Product Range: 55 Series
  • Relay Mounting: Through Hole
  • Coil Type: -
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: -
  • Contact Material: Silver Nickel
  • Coil Resistance: 1.7kohm
  • SVHC: No SVHC (15-Jan-2019)
  • AC Coil Power: 1.5VA
  • Approval Bodies: CDE, CSA, IMQ, SEMKO, SEV, UL
  • Approvals & Standards: CSA, UL, VDE
  • Coil Current: 6mA
  • Coil Operating Lower Percent Limit: 80%
  • Coil Operating Upper Percent Limit: 110%
  • Coil Voltage VAC Nom: 230V
  • Contact Current AC Max: 7A
  • Contact Current Max: 15A
  • Contact Voltage AC Max: 250V
  • Contact Voltage AC Nom: 250V
  • DC Coil Power: 1W
  • External Depth: 33.5mm
  • External Height: 27.5mm
  • External Length / Height: 27.5mm
  • External Width: 20.6mm
  • Lead Spacing: 0.5mm
  • Nom Operating Power: 1.5VA
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: -40°C
  • Relay Type: Power
  • Row Pitch: 1.2mm
