BELDEN - 549945 010500 - Multicore Cable, Screened, 3 Core, 20 AWG, 0.519 mm², 500 ft, 152.4 m
- Cable Shielding: Screened
- No. of Cores: 3Core
- Wire Gauge: 20AWG
- Conductor Area CSA: 0.519mm²
- Reel Length (Imperial): 500ft
- Reel Length (Metric): 152.4m
- Jacket Colour: Black
- No. of Max Strands x Strand Size: 7 x 0.405mm
- Conductor Material: Copper
- Jacket Material: PVC
- External Diameter: -
- Voltage Rating: 300V
- Product Range: -
- SVHC: No SVHC (15-Jan-2018)
- Attenuation @ 100MHz: 2.6dB
- Attenuation @ 10MHz: 0.9dB
- Attenuation @ 1GHz: 8.5dB
- Attenuation @ 1MHz: 0.3dB
- Attenuation @ 200MHz: 3.6dB
- Attenuation @ 400MHz: 5dB
- Attenuation @ 50MHz: 1.9dB
- Attenuation @ 5MHz: 0.65dB
- Cable Type: Braided Shield
- Coaxial Cable Type: RG59
- Complex Cable Make-Up: 1 / 1 / 20 + 2 / 7 / 26
- Conductor Make-up: 7 / 26AWG
- Core-Screen Capacitance: 16.3pF/ft
- Dimensions: 6.89mm x 11.68mm
- Impedance: 75ohm
- Operating Temperature Max: 80°C
- Operating Temperature Min: -30°C
- Secondary Insulation Colour: Black
- Secondary Insulation Material: PVC
- Velocity of Propagation (%): 83%
- Voltage Rating VAC: 300V
