450HXC68MEFCSN22X30 Cap, 68µF, 450V, Alu Elec RUBYCON

RUBYCONUGS :450HXC68MEFCSN22X30 Code de commande:1415836

Prix:
Prix ​​promotionnel€9,92

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (90 unité)

Documents et téléchargements

description

RUBYCON - 450HXC68MEFCSN22X30 - Electrolytic Capacitor, Snap-in, 68 µF, 450 V, ± 20%, Snap-In, 2000 hours @ 105°C

  • Capacitance: 68µF
  • Voltage Rating: 450V
  • Product Range: HXC Series
  • Lifetime @ Temperature: 2000 hours @ 105°C
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Quick Connect, Snap-In
  • Diameter: 22mm
  • Lead Spacing: 10mm
  • Operating Temperature Min: -25°C
  • Operating Temperature Max: 105°C
  • Height: 30mm
  • ESR: -
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2018)
  • Capacitance Tolerance ±: ± 20%
  • External Length / Height: 30mm
  • No. of Pins: 2Pins
  • Operating Life Temperature: 105°C
  • Operating Temperature Range: -25°C to +105°C
  • Operating life Time: 2000h
  • Ripple Current AC: 0.67mA
  • Ripple Current Temperature: 105°C
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Voltage Rating V DC: 450V
