BELDEN - 4506FE.00100 - Multicore Cable, Security Alarm, Screened, 8 Core, 22 AWG, 0.352 mm², 328 ft, 100 m
- Cable Shielding: Screened
- No. of Cores: 8Core
- Wire Gauge: 22AWG
- Conductor Area CSA: 0.352mm²
- Reel Length (Imperial): 328ft
- Reel Length (Metric): 100m
- Jacket Colour: Grey
- No. of Max Strands x Strand Size: 7 x 30AWG
- Conductor Material: Copper
- Jacket Material: FR NC
- External Diameter: 5mm
- Voltage Rating: 300V
- Product Range: -
- SVHC: No SVHC (15-Jan-2018)
- Cable Type: Foil Shield
- Conductor Make-up: 7 / 30mm
- Core - Core Capacitance: 105pF/m
- Core-Screen Capacitance: 185pF/m
- Current Rating: 2A
- Insulation Resistance: 54ohm/km
- Operating Temperature Max: 70°C
- Operating Temperature Min: -20°C
- Outer Diameter: 5mm
- Secondary Insulation Colour: Grey
- Secondary Insulation Material: Frnc
- Voltage Rating VAC: 300V
- Wire Size: 22AWG
