4-1393240-5 Relay, SPST-NO, 250VAC, 16A SCHRACK - Te Connectivity

SCHRACK - TE CONNECTIVITYUGS :4-1393240-5 Code de commande:4219480

Prix:
Prix ​​promotionnel€3,48

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (1548 unité)

Documents et téléchargements

description

SCHRACK - TE CONNECTIVITY - 4-1393240-5 - General Purpose Relay, Power PCB Relay RT1 Series, Power, Non Latching, SPST-NO, 12 VDC, 16 A

  • Contact Configuration: SPST-NO
  • Coil Voltage: 12VDC
  • Contact Current: 16A
  • Product Range: RT1 Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: -
  • Contact Material: Silver Nickel
  • Coil Resistance: 360ohm
  • SVHC: No SVHC (15-Jan-2019)
  • Approvals & Standards: CSA, UL, VDE
  • Coil Voltage VDC Nom: 12V
  • Contact Current DC Max: 16A
  • Contact Current Max: 16A
  • Contact Voltage AC Nom: 250V
  • Contact Voltage DC Max: 110V
  • DC Coil Power: 400mW
  • External Depth: 12.7mm
  • External Height: 15.7mm
  • External Length / Height: 15.7mm
  • External Width: 29mm
  • Nom Operating Power: 400mW
  • Relay Type: Power
