39532304 Socket FFC/FPC, ZIF, 1.25mm, 30WAY Molex

MOLEXUGS :39532304 Code de commande:9786082

Prix:
Prix ​​promotionnel€4,50

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (1019 unité)

Documents et téléchargements

description

MOLEX - 39532304 - FFC / FPC Board Connector, ZIF, 1.25 mm, 30 Contacts, Receptacle, Easy-On 5597, Through Hole, Top

  • Pitch Spacing: 1.25mm
  • No. of Contacts: 30Contacts
  • Gender: Receptacle
  • Product Range: Easy-On 5597 Series
  • Contact Termination Type: Through Hole
  • Contact Position: Top
  • No. of Rows: 1 Row
  • Contact Plating: Tin-Bismuth Plated Contacts
  • Contact Material: Phosphor Bronze
  • FFC/FPC Thickness: 0.3mm
  • SVHC: No SVHC (15-Jan-2019)
  • Contact Resistance: 20mohm
  • Contact Termination: Through Hole Vertical
  • Current Rating: 1A
  • Flammability Rating: UL94V-0
  • Lead Spacing: 1.25mm
  • No. of Rows: 1Rows
  • Operating Temperature Max: 80°C
  • Operating Temperature Min: -20°C
  • Voltage Rating VAC: 200V
