38.51.0.240.0060 Relay, SPDT, 250VAC, 6a Finder

FINDERUGS :38.51.0.240.0060 Code de commande:1169356

Prix:
Prix ​​promotionnel€36,06

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (203 unité)

Documents et téléchargements

description

FINDER - 38.51.0.240.0060 - General Purpose Relay, 38 Series, Interface, SPDT, 240 V, 6 A

  • Contact Configuration: SPDT
  • Coil Voltage: 240V
  • Contact Current: 6A
  • Product Range: 38 Series
  • Relay Mounting: DIN Rail
  • Coil Type: -
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Screw
  • Contact Voltage VDC: -
  • Contact Material: Silver Nickel
  • Coil Resistance: -
  • SVHC: No SVHC (15-Jan-2019)
  • Approval Bodies: BEAB, CSA, DEMKO, IMQ, SEMKO, SETI, SEV, UL, VDE
  • Approvals & Standards: CE, CSA, UL
  • Average Power Consumption: 1VA
  • Coil Voltage VAC Nom: 240V
  • Coil Voltage VDC Nom: 240V
  • Contact Current AC Max: 6A
  • Contact Current Max: 10A
  • Contact Voltage AC Max: 250V
  • Contact Voltage AC Nom: 250V
  • Current Rating: 6A
  • Dielectric Strength VDC: 1000VAC
  • External Depth: 75.6mm
  • External Height: 87.9mm
  • External Length / Height: 87.3mm
  • External Width: 6.2mm
  • IP / NEMA Rating: IP20
  • Mechanical Life: 10,000,000 Operations
  • No. of Mechanical Operations: 10000000
  • Operating Temperature Max: 55°C
  • Operating Temperature Min: -40°C
  • Operating Time: 7ms
  • Relay Type: Interface
  • Release Time: 11ms
  • Switch Current Max: 10A
