3403.0174 Fuse, 6.3a, 250VAC, SMT Schurter

SCHURTERUGS :3403.0174 Code de commande:1510872

Prix:
Prix ​​promotionnel€1,42

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (123 unité)

Documents et téléchargements

description

SCHURTER - 3403.0174 - Fuse, Surface Mount, 6.3 A, Slow Blow, 250 VAC, 125 VDC, 4012, UMT 250

  • Fuse Current: 6.3A
  • Product Range: UMT 250 Series
  • Voltage Rating VAC: 250VAC
  • Voltage Rating V DC: 125VDC
  • Blow Characteristic: Time Delay
  • Fuse Case Style: SMD
  • Breaking Capacity Current AC: 100A
  • Breaking Capacity Current DC: 100A
  • SVHC: No SVHC (15-Jan-2019)
  • Approval Bodies: CCC, JET, KTL, PSE, UMF, VDE
  • Approval Category: UL Recognised
  • Breaking Capacity: 100A @ 250V AC, 125V DC, 35A @ 250V DC, 200A @ 63V AC / DC
  • Breaking Capacity Current UL: 200A
  • Case Material: Ceramic
  • External Depth: 3mm
  • External Length / Height: 3mm
  • External Width: 10.1mm
  • Flammability Rating: UL 94V - 1
  • Fuse Breaking Capacity Voltage AC: 250VAC
  • Fuse Type Blowing Characteristic: Time Lag T
  • Operating Temperature Max: 125°C
  • Operating Temperature Min: -55°C
  • Standard: IEC 60127-4, UL 248-14- CSA C22.2 no. 248.14
  • Voltage Drop @ Rated Current: 300mV
