3386P-1-503LF Trimmer, 50k Bourns

BOURNSUGS :3386P-1-503LF Code de commande:9355120

Prix:
Prix ​​promotionnel€2,99

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (27 unité)

Documents et téléchargements

description

BOURNS - 3386P-1-503LF - Trimpot, Single Turn, Cermet, Top Adjust, 50 kohm, Through Hole, 1 Turns

  • Track Resistance: 50kohm
  • No. of Turns: 1Turns
  • Potentiometer Mounting: Through Hole
  • Product Range: Trimpot 3386 Series
  • Power Rating: 500mW
  • Resistance Tolerance: ± 10%
  • Temperature Coefficient: ± 100ppm/°C
  • Automotive Qualification Standard: -
  • MSL: -
  • SVHC: No SVHC (15-Jan-2019)
  • Adjustment Type: Screwdriver Slot
  • Contact Resistance Variation +: 1%
  • End Resistance: 2ohm
  • External Length / Height: 4.8mm
  • Full Power Rating Temperature: 85°C
  • Lead Diameter: 0.5mm
  • Operating Temperature Max: 125°C
  • Operating Temperature Min: -55°C
  • Operating Temperature Range: -55°C to +125°C
  • Proof Voltage: 900V
  • Resistance: 50kohm
  • Resistor Element Material: Cermet
  • Rotation Mechanical Angle: 310°
  • Temperature Coeff. +: 100ppm/°C
  • Temperature Coeff. -: 100ppm/°C
  • Tolerance +: 10%
  • Tolerance -: 10%
  • Track Taper: Linear
  • Voltage Rating: 300V
  • Voltage Rating V DC: 300V
