description
RUBYCON - 25ZLG100MEFC6.3X11 - Electrolytic Capacitor, Miniature, 100 µF, 25 V, ± 20%, Radial Leaded, 2000 hours @ 105°C, Polar
- Capacitance: 100µF
- Voltage Rating: 25V
- Product Range: ZLG Series
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Radial Leaded
- Diameter: 6.3mm
- Lead Spacing: 2.5mm
- Height: 11mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 105°C
- Lifetime @ Temperature: 2000 hours @ 105°C
- ESR: -
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
- Capacitance Tolerance ±: ± 20%
- External Length / Height: 11mm
- Frequency Tolerance: 120Hz
- Impedance: 0.065ohm
- Impedance Frequency: 100kHz
- Impedance Temperature: 20°C
- Lead Diameter: 0.5mm
- No. of Pins: 2Pins
- Operating Temperature Range: -40°C to +105°C
- Operating life Time: 2000h
- Ripple Current AC: 760mA
- Ripple Current Frequency: 100kHz
- Ripple Current Temperature: 105°C
- Tolerance +: 20%
- Tolerance -: 20%
- Tolerance Temperature: 20°C
- Voltage Rating V DC: 25V
- Voltage Rating VAC: 25V
