HARTING - 21 02 151 2405 - Sensor Connector, HARAX Series, M8, Male, 4 Positions, IDC / IDT Pin, Straight Panel Mount
- Product Range: HARAX Series
- Sensor Connector Size: M8
- Gender: Receptacle
- No. of Contacts: 4Contacts
- Sensor Contact Type: IDC / IDT Pin
- Sensor Connector Mounting: Straight Panel Mount
- IP / NEMA Rating: IP67
- Connector Coding: -
- Connector Body Material: Nylon (Polyamide) Body
- Contact Material: Copper Alloy
- Contact Plating: Gold
- Current Rating: 4A
- Voltage Rating: 32V
- SVHC: No SVHC (15-Jan-2018)
- Approval Bodies: UL
- Cable Diameter Max: 5.4mm
- Cable Diameter Min: 3.2mm
- Connector Insert Type: M8-4
- Connector Mounting: Cable Mount
- Connector Type: Circular Industrial
- Contact Gender: Socket
- Contact Termination: Crimp
- For Use With: 4 Position M8 Sensors & Actuators
- Operating Temperature Max: +50°C
- Operating Temperature Min: -5°C
- Range: M8-S
- Wire Area Size Max: 0.34mm²
- Wire Area Size Min: 0.14mm²
- Wire Size AWG Max: 22AWG
- Wire Size AWG Min: 26AWG
- Working Voltage: 32V
