19N402 Microswitch, v4, Plunger ITW Switches

ITW SWITCHES - 19N402 - Microswitch, Snap Action, Plunger, SPDT, Solder, 5 A, 28 VDC

• Microswitch Type: Snap Action
• Microswitch Actuator: Plunger
• Contact Configuration: SPDT
• Switch Terminals: Solder
• Contact Current Max: 5A
• Contact Voltage DC Nom: 28VDC
• Product Range: 19N Series
• Contact Voltage AC Nom: 250VAC
• Operating Force Max: 2N
• SVHC: No SVHC (17-Dec-2015)
• Actuation Type: Plunger
• Actuator Type: Plunger
• Contact Current AC: 5A
• Contact Current AC Max: 5A
• Contact Current DC Max: 3A
• Contact Current Rating: 5A
• Contact Voltage AC Max: 250V
• Contact Voltage DC Max: 28V
• Differential Travel Max: 0.2mm
• External Depth: 6.35mm
• External Length / Height: 11.1mm
• External Width: 19.9mm
• Fixing Centres: 9.53mm
• Flammability Rating: UL94V-0
• IP / NEMA Rating: IP67
• No. of Electrical Operations: 100000
• No. of Mechanical Operations: 10000000
• Operating Force: 2N
• Operating Temperature Max: 125°C
• Operating Temperature Min: -40°C
• Pre-travel: 1.2mm
• Release Force: 0.27N
• Switch Case: Nylon 4.6 (Polyamide 4.6)
• Switch Operation: On-(On)
