description
BUCHANAN - TE CONNECTIVITY - 1776261-4 - Wire-To-Board Terminal Block, 5 mm, 4 Ways, 22 AWG, 14 AWG, 2 mm², Push In
- Pitch Spacing: 5mm
- No. of Positions: 4Ways
- Wire Size AWG Min: 22AWG
- Wire Size AWG Max: 14AWG
- Conductor Area CSA: 2mm²
- Wire Connection Method: Push In
- Rated Current: 10A
- Rated Voltage: 300V
- Block Orientation: Through Hole Right Angle
- Product Range: -
- SVHC: No SVHC (15-Jan-2019)
- Approval Bodies: CSA
- Colour: Green
- Connector Mounting: PCB Mount
- Connector Type: Terminal Block, Eurostyle
- Contact Current Rating: 15A
- Contact Material: Copper
- Contact Plating: Tin Plated Contacts
- Lead Spacing: 5mm
- Voltage Rating VAC: 300V
- Wire Area Size Max: 2.08mm²
