VXI POWER - 14431-000 - Linear Power Supply, ITE, 2 Outputs, 1 W, 15 V, 40 mA, -15 V
- No. of Outputs: 2Outputs
- Output Power Max: 1W
- Output Voltage - Output 1: 15V
- Output Current - Output 1: 40mA
- Output Voltage - Output 2: -15V
- Output Current - Output 2: 40mA
- Input Voltage VAC: 207V AC to 253V AC
- Product Range: -
- Power Supply Output Type: Fixed
- Output Current - Output 3: -
- SVHC: No SVHC (15-Jan-2018)
- Approval Bodies: CE
- External Depth: 50mm
- External Length / Height: 30mm
- External Width: 50mm
- Height: 30mm
- Input Voltage AC Max: 253V
- Input Voltage AC Min: 207V
- Length: 50mm
- Operating Temperature Max: 40°C
- Operating Temperature Min: 0°C
- Output Ripple Voltage pk-pk: 10mV
- Power Supply Type: Linear
- Supply Frequency Max: 63Hz
- Supply Frequency Min: 47Hz
- Supply Voltage: 240V
- Supply Voltage Max: 250V
- Supply Voltage Min: 210V
- Supply Voltage Typ: 230V AC
- Width: 50mm
