1136103 Cable, Ctrl, CY, 3CORE, 0.75mm, Per M Lapp Kabel

LAPP KABELUGS :1136103 Code de commande:1491553

Prix:
Prix ​​promotionnel€3,43

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (84 unité)

Documents et téléchargements

description

LAPP KABEL - 1136103 - Multicore Cable, Ölflex® CY, Per M, Screened, 3 Core, 19 AWG, 0.75 mm²

  • Cable Shielding: Screened
  • No. of Cores: 3Core
  • Wire Gauge: 19AWG
  • Conductor Area CSA: 0.75mm²
  • Reel Length (Imperial): -
  • Reel Length (Metric): -
  • Jacket Colour: Grey
  • No. of Max Strands x Strand Size: 24 x 0.2mm
  • Conductor Material: Copper
  • Jacket Material: PVC
  • External Diameter: 6.5mm
  • Voltage Rating: 500V
  • Product Range: -
  • SVHC: No SVHC (15-Jan-2019)
  • Bend Radius Min: 20mm
  • Cable Type: CY
  • Conductor Make-up: 24 / 0.2mm
  • Core-Earth / Core-Core Voltage Rating: 300/500
  • Current Rating: 6A
  • Flexing Temperature Max: 70°C
  • Flexing Temperature Min: -5°C
  • Installed Bend Radius Min: 6
  • Insulation Resistance: 20Gohm
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: -30°C
  • Outer Diameter: 6.5mm
  • Secondary Insulation Colour: Grey
  • Secondary Insulation Material: PVC
  • Shield Material: Tinned Copper
  • Shield Type: Tinned Copper Braid
  • Test Voltage: 4000V
