BLOCK - VC 3.2/2/12 - PCB Transformer, PCB, Encapsulated Safety Isolating, 230V, 2 x 12V, 3.2 VA, 50Hz / 60Hz
- Power Rating: 3.2VA
- Secondary Voltages: 2 x 12V
- Current Rating: 133mA
- Isolation Transformer Primary Voltages: 1 x 230V
- Plug Type: -
- Product Range: VC Series
- SVHC: No SVHC (12-Jan-2017)
- AC Power: 3.2VA
- External Depth: 28.1mm
- External Length / Height: 41mm
- External Width: 35mm
- Hole Spacing - Length: 25mm
- Input Voltage: 230V
- Lead Spacing: 5mm
- Output 2 Voltage Max: 12V
- Output Voltage: 12V
- Pin Diameter: 0.8mm
- Pin Length: 5mm
- Pitch Spacing: 20mm
- Primary Voltages: 1 x 230V
- Secondary Power: 1.6VA
- Single Primary Voltage: 230
- Supply Frequency Max: 60Hz
- Supply Frequency Min: 50Hz
- Test Voltage: 5kV
- Transformer Type: Encapsulated
- Weight: 150g
