TIW 06-103 PSU, AC/DC, 1.2A, 4W, Module TRACO Power

TRACO POWERUGS :TIW 06-103 Code de commande:1869147

Prix:
Prix ​​promotionnel€59,57

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
Seulement 2 produits disponibles

Documents et téléchargements

description

TRACO POWER - TIW 06-103 - AC/DC Enclosed Power Supply (PSU), ITE & Household, 1 Outputs, 4 W, 3.3 V, 1.2 A

  • No. of Outputs: 1Outputs
  • Output Power Max: 4W
  • Output Voltage - Output 1: 3.3V
  • Output Current - Output 1: 1.2A
  • Output Voltage - Output 2: -
  • Output Current - Output 2: -
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Output Voltage - Output 4: -
  • Current, Output 4: -
  • Input Voltage VAC: 93V AC to 264V AC
  • Power Supply Output Type: Fixed
  • Product Range: TIW Series
  • SVHC: No SVHC (27-Jun-2018)
  • Applications: General Purpose
  • Height: 23.6mm
  • Input Frequency: 63Hz
  • Input Voltage: 93V AC to 264V AC
  • Input Voltage AC Max: 264V
  • Input Voltage AC Min: 93V
  • Length: 50.2mm
  • No. of Outputs: 1 Output
  • Operating Temperature Max: 50°C
  • Output Current Max: 1.2A
  • Power Rating: 4W
  • Supply Voltage Typ: 115V AC, 230V AC
  • Width: 48mm
