TES 1-2422 DC/DC, 24V/±12V, 1W, SMD TRACO Power

TRACO POWERUGS :TES 1-2422 Code de commande:1635265

Prix:
Prix ​​promotionnel€12,49

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (22 unité)

description

TRACO POWER - TES 1-2422 - Isolated Surface Mount DC/DC Converter, ITE, 1:1, 1 W, 2 Output, 12 V, 40 mA

  • No. of Outputs: 2 Output
  • Output Power Max: 1W
  • Output Voltage - Output 1: 12V
  • Output Current - Output 1: 40mA
  • Output Voltage - Output 2: -12V
  • Output Current - Output 2: 40mA
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Product Range: -
  • Input Voltage DC Min: 21.6V
  • Input Voltage DC Max: 26.4V
  • DC / DC Converter Output Type: Fixed
  • DC / DC Converter Type: Surface Mount DIP
  • DC / DC Converter Mounting: Surface Mount Device
  • Width: 8mm
  • Height: 7mm
  • Depth: 16.3mm
  • SVHC: No SVHC (27-Jun-2018)
  • Efficiency: 78%
  • External Depth: 7mm
  • External Length / Height: 13.7mm
  • External Width: 8mm
  • Isolation Voltage: 1.5kV
  • No. of Outputs: 2Outputs
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -40°C
  • Output Current - Max: -40mA
  • Output Voltage +: 12V
  • Output Voltage -: -12V
  • Power Rating: 1W
  • Supply Voltage: 24V
