BOURNS - SRR0604-331KL - Power Inductor (SMD), 330 µH, 200 mA, Shielded, 280 mA, SRR0604
- Inductance: 330µH
- RMS Current (Irms): 200mA
- Inductor Construction: Shielded
- Saturation Current (Isat): 280mA
- Product Range: SRR0604 Series
- Power Inductor Case: 6.5mm x 6.5mm x 4.8mm
- DC Resistance Max: 2.1ohm
- Inductance Tolerance: ± 10%
- SVHC: No SVHC (15-Jan-2018)
- Q Factor: 18
- Q Test Frequency: 796kHz
- Self Resonant Frequency Min: 7MHz
