BOURNS - SRP4012TA-8R2M - Power Inductor (SMD), 8.2 µH, 1.4 A, Shielded, 1.6 A, SRP4012TA, 4.45mm x 4.06mm x 1mm
- Inductance: 8.2µH
- RMS Current (Irms): 1.4A
- Inductor Construction: Shielded
- Saturation Current (Isat): 1.6A
- Product Range: SRP4012TA Series
- Power Inductor Case: 4.45mm x 4.06mm x 1mm
- DC Resistance Max: 0.376ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2018)
- Automotive Qualification Standard: AEC-Q200
